Model MP-450
The MP-450 centrifugal fan is manufactured entirely from polypropylene, specifically designed to provide corrosion resistance in demanding industrial environments. Following our technical nomenclature, this model features an inlet and outlet diameter of 450 mm, which facilitates seamless integration into your extraction system.
Custom-built and featuring a direct drive design, the MP-450 guarantees maximum mechanical efficiency for flow rates of up to 17,500 m³/h. Furthermore, it is available with various power ratings and rotation speeds, reaching a maximum pressure of 214 mmwc (millimeters of water column).
Fan MP-450 4kW 1500rpm
| Max Flow Rate: | 11,300 m³/h |
| Min Flow Rate: | 600 m³/h |
| Max Pressure: | 150 mmwc |
| Motor Power: | 4.0 kW |
| Speed (RPM): | 1,500 |
| Sound Pressure Level: | 89 dB |
| Weight: | 150 Kg |
| Max Intensity 400v: | 8.8 A |
| *With free outlet at 1.5m. | |
Fan MP-450 11kW 1500rpm
| Max Flow Rate: | 17,500 m³/h |
| Min Flow Rate: | 7,729 m³/h |
| Max Pressure: | 214 mmwc |
| Motor Power: | 11.0 kW |
| Speed (RPM): | 1,500 |
| Sound Pressure Level: | 87 dB |
| Weight: | 200 Kg |
| Max Intensity 400v: | 20.7 A |
| *With free outlet at 1.5m. | |
Characteristic Curves: MP-450
*Tests carried out according to ISO 5801 standard.
*The lines show performance at 50Hz, 45Hz, and 40Hz.
Do you need to verify the compatibility of a specific compound with our materials?
FAN DIMENSIONS
| Model | Unit | A | B | C | D | E | F | G | H | I | J | K | L |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MP-450 4kW 1500rpm | mm | 320 | 605 | 450 | 450 | 1179 | 1167 | 712 | 540 | 500 | 280 | 354 | 857.0 |
| Inch | 12.6 | 23.8 | 17.7 | 17.7 | 46.4 | 45.9 | 28.0 | 21.3 | 19.7 | 11.0 | 13.9 | 33.7 | |
| MP-450 11kW 1500rpm | mm | 365 | 769 | 569 | 450 | 1446 | 1488 | 930 | 616 | 550 | 350 | 551 | 1076.0 |
| Inch | 14.4 | 30.3 | 22.4 | 17.7 | 56.9 | 58.6 | 36.6 | 24.3 | 21.7 | 13.8 | 21.7 | 42.4 |
Energy Efficiency: High-efficiency IE3 motors.
ATEX Version: Available in PP-EL-S (electro-conductive) version for Zones 1 and 2, strictly complying with Directive 2014/34/EU. Available with motors for various voltages and frequencies, ensuring compatibility for projects anywhere in the world. Recommended working temperature range from -10ºC to +85ºC. Motors with IE3 efficiency.
*The ECODESIGN Directive 2009/125/EC does not apply to the Anti-corrosive fan range. It is recommended that MP series fans be controlled by a variable frequency drive.
